T & T Marketing Wire and Cable Blog

Outdoor, Flame Retardant, TPV Grades Available

Posted by Jessica Hoogendoorn

Oct 1, 2015 12:09:48 PM

The following two grades offered by T & T Marketing are highly flame retardant and will meet UL f1 or f2 weatherability ratings.

TPE 5170
TPE 5170 is a soft, natural, weatherable, flame retardant thermoplastic vulcanizate (TPV) compound for applications requiring excellent ozone resistance and resistance to flex fatigue. This material has good fluid resistance and is formulated to replace thermoset rubbers such as EPDM, polychloroprene and chlorosulphonated polyethylene.

TPE 5170 complies with "Restriction of Hazardous Substances" Directive, Citation 2002-95-EC, commonly known as RoHS. TPE 5170 contains a halogen-based, flame retardant additive package designed to reduce normal flame spread characteristics. It is shear-dependent and can be processed on conventional thermoplastics equipment for injection molding, extrusion or blow molding. It is polyolefin based and completely recyclable. The formulation for this compound was acquired by T & T Marketing from ExxonMobil Chemical.


151-70W256
Santoprene
Santoprene™ 151-70W256 is a soft, black, flame retardant thermoplastic vulcanizate (TPV).

This material has been designed to meet the Underwriter Laboratories (UL) Subjects 6703, 6703A, 3730 and 1703 material requirements for both junction boxes and connectors (both enclosure and insulation) for use in photovoltaic systems.

The flame retardants used are RoHS compliant and provide UL 94 flammability classifications of V-1 down to a thickness of 1.5 mm and 5VA down to a thickness of 1.8 mm. The material has an elevated Relative Thermal Index (RTI) of 90°C and meets the requirements for suitability for outdoor use with an f1 rating. This grade of Santoprene™ TPV is shear-dependent and can be processed on conventional thermoplastics equipment for injection molding. It is polyolefin based and recyclable within the manufacturing stream.

Read More

Topics: Products

New Zero Halogen, Horizontal FR, Moisture Cure Systems Bulletinized for UL 44 and UL 854

Posted by Jessica Hoogendoorn

Sep 8, 2015 3:43:33 PM


T & T Marketing now offers two zero halogen, moisture-induced crosslinking polyethylene compound systems that are designed for use as low voltage wire insulation and jacketing.

These systems are recommended for use as insulation and sheath for low voltage control cables and power cables up to 6kv in rating. Both also contain a patented scorch retardant additive (SRA) that increases the processing window for a moisture crosslinking compound and minimizes the tendency for premature crosslinking in the extruder, head or die.

FR4450/LE4433 (black)
The combination of a Visico FR4450 base resin, and the LE4433 catalyst, provides a highly scorch retardant compound with excellent thermal stability and good flame retardant properties.

FR4450/LE4433 is designed to reduce normal PE flame spread characteristics and achieve an HB-1 flame rating on 14 AWG wires and larger. LE4433 also provides, in addition to catalyst, a stabilization package containing suitable antioxidants, a metal deactivator and fine particle size carbon black for UV weather resistance.

FR4450/LE4439 (natural)
The combination of a Visico FR4450 base resin, and the LE4439 catalyst, provides a highly scorch retardant compound with excellent thermal stability and good flame retardant properties.

FR4450/LE4439 is designed to reduce normal PE flame spread characteristics and achieve an HB-1 flame rating on 14 AWG wires and larger. LE4439 also provides, in addition to catalyst, a stabilization package containing suitable antioxidants, a metal passivator and a metal deactivator. Properly mixed, during the extrusion process, FR4450/LE4439 exhibits excellent thermal stability to oxidation.
FR4450/LE4439 is readily pigmented to a variety of colors using standard wire & cable color concentrates designed for thermoplastic or crosslinked polyethylene.

Request More Information
Read More

Topics: Products

Find Out What's New at T & T Marketing

Posted by Jessica Hoogendoorn

Sep 2, 2015 9:35:12 AM

The following is a selection of new product offerings from T & T Marketing.

Borealis

  • Non-halogen, horizontal FR, moisture cure XL compounds for LV insulation and jacketing, bulletinized for UL 854 and UL 44
    • FR4450/LE4433 - black
    • FR4450/LE4439 – natural

HUNTSMAN TPU

  • IROGRAN A78P 4766NM – smooth surface, halogen free, V-0 flame retardant, low S.G.

S&E Specialty Polymers

  • TufGuard E CPE compounds - thermoplastic and e-beam crosslinkable
  • TufFlex flexible TPE alloys - wide temperature range, oil resistant
  • TufPrene SEBS and SBS compounds - very flexible at low temperature
  • TufFill - Non-halogen compounds with up to 49 LOI
  • TufFill – Halogen FR concentrates

T & T Compounds & Masterbatches

  • EXP 5595 LSZH - a very low smoke, zero halogen flame retardant thermoplastic elastomer
    • 125C rated and VW-1, appliance wire, flexible cord and power limited tray cable
  • EXP 5187 LSZH - an oil resistant very low smoke zero halogen flexible flame retardant thermoplastic vulcanizate
  • TPE 2575 HFFR - thermoplastic vulcanizate (TPV) compound for flexible wire and cable jacketing applications that can provide cable makers with halogen free VW-1 flame performance

ECC EPDM Compounds

  • EP-MC 16 when mixed with FMB 5008 and CMB 432 - - UL 44 bulletin
  • Flexible moisture cure resin EP-MC 4 and EP-MC 2
  • FMB 5150 FR/Catalyst master batch – 150C applications

Hanwha EVA (Ethylene Vinyl Acetate)

  • High VA Grades: EVA 1540 – 40% VA, 60 MI

UNITAPE® Products

  • Double sided, 0.2 mm thick, Water Blocking Tape - Pads and traverse spools available



Read More

Topics: Products

TPU Grades for Wire and Cable Applications

Posted by Jessica Hoogendoorn

Aug 25, 2015 9:49:42 AM

T & T Marketing offers an extension range of Huntsman IROGRAN® Thermoplastic Polyurethanes (TPU) for extrusion applications. TPU is used in wire and cable applications when high flexibility/elasticity, excellent abrasion resistance, very good cut resistance, high bending stability, and halogen-free characteristics are needed.

Typical applications include cable jacketing for oil and gas exploration, mining cables, automotive brake systems, military, robotics and industrial cables and coiled cables.

Download the TPU Brochure

A 78 P 4766NM

Flame-retardant, halogen-free,polyether based thermoplastic polyurethane intended for extrusion and injection moulding applications. Has UL 94 Classification V0.

View the data sheet.

A 85 P 4854

A flame-retardant, halogen-free polyether based TPU. Characteristics include high tensile strength, excellent wear performance, excellent hydrolysis and microbial resistance, good low temperature flexibility, matte surface, and UL 94 Classification V0. Ideal for applications requiring a moderate level of flame retardancy and good processing.

View the data sheet.

A 85 P 4394

A standard, glossy polyether based TPU. Characteristics include high tensile strength, excellent wear performance, excellent hydrolysis and microbial resistance and good low temperature flexibility.

View the data sheet.

A 85 P 4394 UV

A high performance polyether based thermoplastic polyurethane. Offers a specially designed, flexible material with a broad processing window particularly suitable for the preparation of tubing, cable jacketing and technical mouldings.

 View the data sheet.

Read More

Topics: Products, TPU

New Moisture Cure and Low Smoke Zero Halogen Offerings

Posted by Jessica Hoogendoorn

Aug 4, 2015 10:40:57 AM

Introducing AquaGraft Moisture Cure

T & T Marketing is now distributing Electric Cable Components' (ECC) AquaGraft line of moisture cure products. All products are RoHS compliant.

16-5150 (EP Base)
This is a flexible moisture crosslinkable, natural, XLPO grafted polymer system that is composed of EPMC-16 and FMB-5150 FR/catalyst master batch. These two components are supplied in pellet form, and when blended in the proper ratios, will meet various low voltage and specialty wire and cable requirements.

AquaGraft 16-5150 is designed for use in UL/CSA 150C rated AWM cable applications. These two components, when blended in a 70% EPMC-16/30% FMB-5150 blend ratio, will yield a finished compound which will allow the cable to pass various industry recognized requirements and be suitable for flame retardant 150C applications.

When extruded and cured consistent with standard safe wire and cable industry practices, cable insulated with the correct component ratios will comply with the requirements as specified in the following standards:
UL 150 C Styles 3321
CSA CL-1503 Class 1, Group A/B single conductor 600v XLPE
FT-2 Flame Rating, UL Horizontal Flame


1-5150 (PE Base)
This is a moisture crosslinkable, natural, XLPO grafted polymer system that is composed of PEMC-1 and FMB-5150 FR/catalyst master batch. These two components are supplied in pellet form, and when blended in the proper ratios, will meet various low voltage and specialty wire and cable requirements.

AquaGraft 1-5150 is designed for use in UL/CSA 150C rated AWM cable applications. These two components, when blended in a 70% PEMC-1/30% FMB-5150 blend ratio, will yield a finished compound which will allow the cable to pass various industry recognized requirements and be suitable for flame retardant 150C applications.

When extruded and cured consistent with standard safe wire and cable industry practices, cable insulated with the correct component ratios will comply with the requirements as specified in the following standards:
UL 150 C Styles 3321
CSA CL-1503 Class 1, Group A/B single conductor 600v XLPE
FT-2 Flame Rating, UL Horizontal Flame


LSZH Jacket

T & T distributes various other products for ECC as well, including low smoke, zero halogen jacketing materials.

CableArmor 1750
This is a thermoplastic non-halogenated flame resistant polyolefin jacketing compound (RoHS Compliant).

Cables jacketed with this compound are recognized for balanced properties including excellent flame retardancy, heat and deformation resistance at operating temperatures up to 90C, environmental and chemical resistant properties, and superior mechanical properties.

Cable jacketed with CableArmor 1750 is suitable for use in power, transit, communication, as well as other applications that require excellent flame protection, mechanical properties, and low corrosivity.

Read More

Topics: Products
